Technical Information on Connect Systems Inc. Equipment Compiled and maintained by Mike Morris WA6ILQ |
| Contact Info: | ||||
|
Connect Systems Inc. 18022 Delano Street Encino, CA 91316 |
|
Phone: (818) 889-0503 e-mail: sales //at// connectsystems //dot// com web: http://www.connectsystems.com |
||
| Older manuals showed an address in Ventura, CA. That address is no longer valid. | ||||
Scroll down for some obsolete CSI manuals that were donated by various sources. If anyone has any additional relevant manuals (or software) please drop a note to the page maintainer listed at the top of this page. It seems they mostly sell mobile and portable radios these days.
CSI also sells their own portable and mobile digital radios that are compatible with DMR / MotoTRBO systems.
These units are reasonably priced and chock-full of features that you'd expect from the major brands.
| Product Name |
Product Function / Description |
|---|---|
| CD1 | Communications Decoder (CTCSS/PL, DCS/DPL, DTMF display) Needs +12v, ground, discriminator audio. 1.35 MB PDF file |
| CD2, CD2‑CAR CD‑2P |
Communications Decoder (PL, DPL, DTMF display, serial printer output on a 6-wire RJ-11 jack) 395 KB PDF file Needs +12v, ground, discriminator audio. DO NOT plug a phone line into the RJ11 jack! The CD2-CAR was a DTMF ANI Decoder - it decoded only DTMF strings and held the display until the next string was received. The CD2-CAR was the CD-2 but with a jumper inside... jumper out=CD2, jumper in=CD2-CAR. The CD-2P was an MS-DOS program that displayed the DTMF strings on a computer screen and logged them. Anybody have a copy? |
| CS-700 | Sampling Simplex Phone Patch (Obsolete) 238 KB PDF file |
| CS-800 | Single User Duplex Phone Patch and Repeater Controller 254 KB PDF file |
| CS-900 | Simplex Phone Patch 331 KB PDF file |
| CS-3850 | Shared Repeater Tone Panel 307 KB PDF file |
| CS-8300 | Tone Panel & Telephone Interconnect 308 KB PDF file |
| CS-9800 | "MicroPatch" Simplex and Duplex Phone Patch 1988-1990 version (obsolete) 128 KB PDF file |
| CS-9800 | "MicroPatch" Simplex and Duplex Phone Patch 1990-1991 version (obsolete) 1.92 MB PDF file |
| CS-9800 and CS-9800exp |
"MicroPatch" Simplex and Duplex Phone Patch 1991-1995 version (obsolete) 389 KB PDF file The 9800exp was the Export model. |
| CS6800 | Auto Remote |
| CS8300 | Duplex Phone Patch and Repeater Controller 308 KB PDF file |
| EX-8 | Telephone Line Expander |
| LT-2 | LTR Communications Decoder (Fleet, User ID display) 458 KB PDF file Needs +12v, ground, discriminator audio. This unit has a serial printer output on a 6-wire RJ-11 jack - DO NOT plug a phone line into it! |
| LT-4200 | LTR Repeater Controller (1 channel, 1 rack unit high, 9-pin serial port for management). 108 KB PDF file The 12-pin receiver and transmitter connector on the rear of the housing is a Phoenix MSTB 2.5/12ST-5.08 Photo The mating plug (that would go on the cable) is Phoenix MSTBA 2.5/12G-5.08. There are TWO serial connectors on the unit. The one on the front is a DE-9 FEMALE, used to connect to a PC with a normal M-F cable (only pins 2, 3 and 5). The one on the rear is a DE-9 MALE, designed to connect a modem. Both connectors are wired in parallel (just with a different sex and pinout), you can only use ONE of them at a time. This unit is programmed / managed by the "CSIBASE" program that was shipped with every unit. Your page maintainer has 14 of these in commercial service. The highest firmware vesion seen on this model is 3.00 - supposedly there is a 3.1 out there, your page maintainer would like an image file. |
| LT-4900 | This unit is an extended LT-4200 with a Telephone Interconnect and a Modem (for remote management) added internally. 312 KB PDF file The highest firmware vesion seen on this model is 2.63 |
| TP154 | Community Tone Panel, manual version 3.01 249 KB PDF file |
| TP154 Plus | Community Tone Panel and Interconnect, manual version 3.03 399 KB PDF file |
| TP163 | Community Tone Panel 301 KB PDF file |
| RT8 | Rural Telephone Controller System (both RT8RU and RT8TU units) |
Manuals Not Linked Above
Web page created 14-Oct-2003 by Mike Morris WA6ILQ.
